AA-07BD SILVER

Multi-apartment entrance panel with 4.3″ TFT screen

AA-07BD is a multi-apartment entrance panel with a backlit TFT color screen, and a high-resolution IP camera with wide viewing angles.

WHERE TO BUY

AA-07BD is a multi-apartment entrance panel with a backlit TFT color screen, a high-resolution IP camera with wide viewing angles, and support for BAS-IP UKEY mobile access.

More detailed information about configuration, connection, and installation can be found here.

The specifications and appearance of the device may differ from those stated or may change without prior notice!

Panel type: Multi-apartment

Display: 4,3“ TFT, color, with backlight

Resolution: 2,0 Мp

Сamera angle: 110° (horizontal)

Output video: 1080p (1920×1080), H.264 Main Profile

Night backlight: 6 LEDs

Light sensitivity: 0.01 Lux

IK-Code: IK07

Protection class: IP65

Working temperature: -40 – +65 °С

Operating humidity: 0% – 86%

Storage Humidity: 0% – 60%

Power consumption: 6,5 W, in standby – 3,6 W

Power supply: +12 V DC (+8% -4%)

Case: Aluminum

Colors: Silver

Dimensions: 155×375×55 mm

Installation: Flush mounting, wall mounting with BR-AA

Keyboard: Mechanical buttons with backlight

Box dimensions: 431×200,5×97 mm

Gross weight: 2,68 kg

Interface: Multilanguage, WEB- interface

Lock opening:

• By means of a monitor
• By QR code
• By guest link
• By Pin
• By access card
• The BAS-IP Intercom app
• The BAS-IP UKEY app
• From API

Access control:
• UKEY (EM-Marin/ MIFARE®/NFC/Bluetooth)

Supported standards:

• BLE (Bluetooth Low Energy): 2,45 GHz Bluetooth 4.x, Bluetooth 5.x.
• Mifare®, 13,56 MHz ISO14443A: Mifare®Standard, Mifare®Hi-Memory, Mifare®Ultralight, Mifare®Classic 1K/4K, Mifare®Classic 7UID, Mifare® Plus SL1 and SL3
• NFC, 13,56 MHz: ISO 14443/15693
• Cards 125 kHz: ASK and FSK

Reading range:

• NFC, Mifare cards and 125 kHz cards – up to 5 cm
• BLE – adjustable 10 cm – 10 m

Calling the lift to the floor: Yes

Access control integration:Integrated controller up to 20 000 identifiers and multiformat UKEY reader

Onvif (Profile S): Yes

Integration with ACS: Wiegand
Built-in Wiegand output for card, key fob, and UKEY identifiers: 26, 32, 34, 37, 40, 42, 56, 58, 64, 80 bits
Connection of the additional SH-12 module and its support:
• Wiegand input: from 6 to 58 bits inclusive
• Wiegand output for card, key fob, UKEY, QR, Face, Digital code, and all other types of identifiers: from 26 to 128 bits inclusive

Quick-dial buttons: Concierge call button

Number of ringtones: 4 polyphonic ringtones

Authentication:

• Separate password for settings
• WEB-interface

Additionally:

• Software Link support
• SIP P2P
• Built-in relay
• Open API
